سامانه های الکترواویونیک بالگرد

Illustration pertaining to circuit breakers,   control panel arrangement and face identification are contained in the flight   manual, maintenance instructions, not appearing in this chapter will be   covered n other chapters and higher echelon maintenance manuals, the   following descriptive information is given in this section.a. Control panel for the ac and dc electrical systems are located in pilot   and gunner’s consoles control relays, power relays, voltage regulators, and   other equipment Required to control, regulate, effect power transfer and   malfunction monitoring are located in the nose, gunners and pilot section   (right and left wells), and aft compartment.
